We see the module is explained, the components viewed under magnifier, the boost converter is tested with input voltages of 12V, 19.2V, 24V and output voltage is 18V, 24V, 36V and 48V. Ripple voltages shown, thermal video shows and switching frequency measured.
Please click on the timeline to see the chapters below
00:00 Introduction
5:10 components
9:15 Test input 12V, output 19.2V
10:35 Test input 12V, output 24V
11:11 Test input 12V, output 24V 4A
11:25 Test input 12V, output 24V 8A
11:38 Test input 12V, output 24V 10A
12:19 Test input 12V, output 36V
12:33 Test input 12V, output 36V 4A
12:46 Test input 12V, output 36V 5A
13:05 Test input 12V, output 36V 8A
13:25 Test input 12V, output 36V 10A
13:52 Test input 12V, output 36V 15A
15:57 Test input 12V, output 48V
16:42 Test input 12V, output 48V 5A
17:16 Test input 19.2V, output 24V
18:11 Test input 19.2V, output 36V
19:07 Test input 19.2V, output 48V 5A, 8A
20:13 Test input 19.2V, output 36V
20:35 Test input 19.2V, output 36V 6A
21:05 Test input 24V, output 48V
21:43 Test input 27V, output 36V
24:09 Test input 27V, output 48V
25:46 Thermal images of PW500
29:03 Ripple voltage measurement
33:07 Switching frequency
33:39 Conclusion remarks
